With this tool you can:

• Troubleshoot containers and pods lacking shell and/or debugging tools.

• Forward unpublished or even localhost ports to your host system.

• Expose endpoints from the host system to containers & Kubernetes networks.

• Handily export image's and/or container's filesystem to local folders.

• and more :)

The following commands x runtimes are supported:

Installation

It's a statically linked Go binary, so you know the drill:

GOOS=linux
GOARCH=amd64

curl -Ls https://github.com/iximiuz/cdebug/releases/latest/download/cdebug_${GOOS}_${GOARCH}.tar.gz | tar xvz

sudo mv cdebug /usr/local/bin

Homebrew

If you're a Homebrew user, you can install the tool via brew on macOS or Linux:

$ brew install cdebug

At the moment, the following systems are (kinda sorta) supported:

• linux/amd64

• darwin/amd64

• darwin/arm64

Commands

cdebug exec

Execute commands or start interactive shells in scratch, slim, or distroless containers, with ease:

# Start a busybox:musl shell in the Docker container:
cdebug exec -it mycontainer
cdebug exec -it docker://mycontainer

# Execute a command in the Docker container:
cdebug exec mycontainer cat /etc/os-release

# Use a different debugging toolkit image:
cdebug exec -it --image=alpine mycontainer

# Use a nixery.dev image (https://nixery.dev/):
cdebug exec -it --image=nixery.dev/shell/vim/ps/tshark mycontainer

# Exec into a containerd container:
cdebug exec -it containerd://mycontainer ...
cdebug exec --namespace myns -it containerd://mycontainer ...

# Exec into a nerdctl container:
cdebug exec -it nerdctl://mycontainer ...

# Start a shell in a Kubernetes pod:
cdebug exec -it pod/mypod
cdebug exec -it k8s://mypod
cdebug exec --namespace=myns -it pod/mypod

# Start a shell in a Kubernetes pod's container:
cdebug exec -it pod/mypod/mycontainer

The cdebug exec command is a crossbreeding of docker exec and kubectl debug commands. You point the tool at a running container, say what toolkit image to use, and it starts a debugging "sidecar" container that feels like a docker exec session to the target container:

• The root filesystem of the debugger is the root filesystem of the target container.

• The target container isn't recreated and/or restarted.

• No extra volumes or copying of debugging tools is needed.

• The debugging tools are available in the target container.

By default, the busybox:musl (statically compiled) image is used for the debugger sidecar, but you can override it with the --image flag. Combining this with the superpower of Nix and Nixery, you can get all your favorite tools by simply listing them in the image name:

cdebug exec -it --image nixery.dev/shell/ps/vim/tshark <target-container>

cdebug port-forward

Forward local ports to containers and vice versa. This command is another crossbreeding - this time it's kubectl port-forward and ssh -L|-R.

Currently, only local port forwarding (cdebug port-forward -L) is supported, but remote port forwarding is under active development.

Local port forwarding use cases (works for Docker Desktop too!):

• Publish "unpublished" port 80 to a random port on the host: cdebug port-forward <target> -L 80

• Expose container's localhost to the host system: cdebug port-forward <target> -L 127.0.0.1:5432

• Proxy local traffic to a remote host via the target: cdebug port-forward <target> -L <LOCAL_HOST>:<LOCAL_PORT>:<REMOTE_HOST>:<REMOTE_PORT>

• 🛠️ Expose a Kubernetes service to the host system: cdebug port-forward <target> -L 8888:my.svc.cluster.local:443

Remote port forwarding use cases:

• Start a container/Pod forwarding traffic destined to its <IP>:<port> to a non-cluster endpoint reachable from the host system.

• ...

Examples

Below are a few popular scenarios formatted as reproducible demos.

A simple interactive shell to a distroless container

First, a target container is needed. Let's use a distroless nodejs image for that:

$ docker run -d --rm \
  --name my-distroless gcr.io/distroless/nodejs \
  -e 'setTimeout(() => console.log("Done"), 99999999)'

Now, let's start an interactive shell (using busybox) into the above container:

$ cdebug exec -it my-distroless

Exploring the filesystem shows that it's a rootfs of the nodejs container:

/ $# ls -lah
total 60K
drwxr-xr-x    1 root     root        4.0K Oct 17 23:49 .
drwxr-xr-x    1 root     root        4.0K Oct 17 23:49 ..
👉 lrwxrwxrwx 1 root     root          18 Oct 17 23:49 .cdebug-c153d669 -> /proc/55/root/bin/
-rwxr-xr-x    1 root     root           0 Oct 17 19:49 .dockerenv
drwxr-xr-x    2 root     root        4.0K Jan  1  1970 bin
drwxr-xr-x    2 root     root        4.0K Jan  1  1970 boot
drwxr-xr-x    5 root     root         340 Oct 17 19:49 dev
drwxr-xr-x    1 root     root        4.0K Oct 17 19:49 etc
drwxr-xr-x    3 nonroot  nonroot     4.0K Jan  1  1970 home
drwxr-xr-x    1 root     root        4.0K Jan  1  1970 lib
drwxr-xr-x    2 root     root        4.0K Jan  1  1970 lib64
drwxr-xr-x    5 root     root        4.0K Jan  1  1970 nodejs
...

Notice 👉 above - that's where the debugging tools live:

/ $# echo $PATH
/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin:/.cdebug-c153d669

The process tree of the debugger container is the process tree of the target:

/ $# ps auxf
PID   USER     TIME  COMMAND
    1 root      0:00 /nodejs/bin/node -e setTimeout(() => console.log("Done"),
   13 root      0:00 sh -c  set -euo pipefail  sleep 999999999 & SANDBOX_PID=$!
   19 root      0:00 sleep 999999999
   21 root      0:00 sh
   28 root      0:00 [sleep]
   39 root      0:00 [sleep]
   45 root      0:00 ps auxf

An interactive shell with code editor (vim)

If the tools provided by busybox aren't enough, you can bring your own tools with a little huge help of the nixery project:

$ cdebug exec -it --image nixery.dev/shell/vim my-distroless

An interactive shell with tshark and other advanced tools

Even more powerful exammple:

$ cdebug exec -it --image nixery.dev/shell/ps/findutils/tshark my-distroless

Debugging containerd containers (no Docker required)

First, start the target container:

$ sudo ctr image pull docker.io/library/nginx:latest
$ sudo ctr run -d docker.io/library/nginx:latest nginx-1

Run an interactive shell in the target container using simple cdebug exec:

$ sudo cdebug exec -it containerd://nginx-1
/ $# wget -O- 127.0.0.1

Run VIM in the target container using cdebug exec --image nixery.dev/shell/vim:

$ sudo cdebug exec -it --rm --image nixery.dev/shell/vim containerd://nginx-1

Debugging nerdctl containers (no Docker required)

Start a container using nerdctl:

$ sudo $(which nerdctl) run -d --name nginx-1 nginx
9f8763d82259a6e3e747df83d0ce8b7ee3d33d94269a72cd04e0e3862a3abc5f

Run the debugger using the nerdctl:// schema and the target's name:

$ sudo cdebug exec -it --rm nerdctl://nginx-1

Or run a debugging session in the above container using the containerd:// schema:

$ sudo cdebug exec -it --rm containerd://9f876

Debugging Kubernetes Pods (without node access)

Start the target Pod:

$ kubectl run --image nginx:alpine nginx-1
$ kubectl run --image=nginx:alpine nginx-1 \
  --overrides='{ "apiVersion": "v1", "spec": { "containers": [{ "name": "app", "image": "nginx:alpine" }] } }'
pod/nginx-1 created

$ kubectl get pods
NAME    READY   STATUS    RESTARTS   AGE
nginx-1   1/1     Running   0         5s

Run the debugger in the Pod (it'll start a new ephemeral container):

$ cdebug exec -it pod/nginx-1

Expected output:

Debugger container name: cdebug-3023d11d
Starting debugger container...
Waiting for debugger container...
Attaching to debugger container...
If you don't see a command prompt, try pressing enter.
/ # ps auxf
PID   USER     TIME  COMMAND
    1 root      0:00 sh /.cdebug-entrypoint.sh
   10 root      0:00 /bin/sh -i
   11 root      0:00 ps auxf

Run the debugger in the Nginx container (app):

$ cdebug exec -it pod/nginx-1/app

cdebug exec -it pod/nginx-1/app
Debugger container name: cdebug-b44ca485
Starting debugger container...
Waiting for debugger container...
Attaching to debugger container...
If you don't see a command prompt, try pressing enter.
/ # ps auxf
PID   USER     TIME  COMMAND
    1 root      0:00 nginx: master process nginx -g daemon off;
   30 nginx     0:00 nginx: worker process
   ...
   41 nginx     0:00 nginx: worker process
   42 root      0:00 sh /.cdebug-entrypoint.sh
   51 root      0:00 /bin/ash -i
   52 root      0:00 ps auxf

Debugging Kubernetes Pods (with node access)

Currently, only containerd CRI is supported. First, you'll need to list the running containers:

$ ctr -n k8s.io container ls
CONTAINER       IMAGE                                       RUNTIME
155227c0e9aa8   k8s.gcr.io/pause:3.5                        io.containerd.runc.v2
2220eacd9cb26   registry.k8s.io/kube-apiserver:v1.25.3      io.containerd.runc.v2
22efcb35a651a   registry.k8s.io/etcd:3.5.4-0                io.containerd.runc.v2
28e06cc63b822   docker.io/calico/cni:v3.24.1                io.containerd.runc.v2
30754c8492f18   docker.io/calico/node:v3.24.1               io.containerd.runc.v2
61acdb0231516   docker.io/calico/kube-controllers:v3.24.1   io.containerd.runc.v2
...

Now you can exec into a Pod's container bringing your own debugging tools:

$ cdebug exec -n k8s.io -it --rm containerd://2220ea

Publish "forgotten" port

Start an nginx container but don't expose its port 80:

$ docker run -d --name nginx-1 nginx:1.23

Forward local port 8080 to the nginx's 80:

$ cdebug port-forward nginx-1 -L 8080:80
$ curl localhost:8080

Expose localhost's ports

Start a containerized service that listens only on its localhost:

$ docker run -d --name svc-1 python:3-alpine python3 -m 'http.server' -b 127.0.0.1 8888

Tap into the above service:

$ cdebug port-forward svc-1 -L 127.0.0.1:8888
Pulling forwarder image...
latest: Pulling from shell/socat
Digest: sha256:b43b6cf8d22615616b13c744b8ff525f5f6c0ca6c11b37fa3832a951ebb3c20c
Status: Image is up to date for nixery.dev/shell/socat:latest
Forwarding 127.0.0.1:49176 to 127.0.0.1:8888 through 172.17.0.4:34128

$ curl localhost:49176
<!DOCTYPE HTML>
<html lang="en">
<head>
...

F.A.Q

Q: cdebug exec fails with ln: /proc/1/root/...: Permission denied or the like error?

Non-privileged targets can cause this error because by default, cdebug tries to start the debugger container with the same privileges as the target container. Try cdebug exec --privileged instead.

Similar tools

• slim debug - a debug command for Slim(toolkit) (originally contributed by D4N)

• debug-ctr - a debugger that creates a new container out of the original container with the toolkit mounted in a volume (by Felipe Cruz Martinez)

• docker-debug - much like cdebug exec but without the chroot trick.

• docker-opener - a multi-purpose tool that in particular can run a shell session into your container (and if there is no shell inside, it'll bring its own busybox).

• cntr - is "a replacement for docker exec that brings all your developers tools with you" by mounting the file system from one container (or the host) into the target container and creating a nested container with the help of a FUSE filesystem. Supports a huge range of runtimes (docker, podman, LXC/LXD, rkt, systemd-nspawn, containerd) because it operates on the OS level.

• kdiag - a kubectl plugin to get shell access to scratch containers, stream logs from multiple pods simultaneously, and do reverse port forwarding to Kubernetes clusters.

• kpexec - a CLI that runs commands in a Kubernetes container with high privileges (via a privileged Pod with Node access).

TODO:

• More exec flags (like in docker run): --cap-add, --cap-drop, --env, --volume, etc.

• Helper command(s) suggesting nix(ery) packages

• Non-docker runtimes (Podman, CRI, OCI)

• More E2E Tests

Contributions

It's a pre-alpha with no sound design yet, so I may not be accepting all PRs. Sorry about that :)
